Why Built-in Light Handlebar?

The head light is necessary equipment for the safety of night riding, but there are not much space on the handle bar with brake lever, gear lever, and various cables. Since the Built-in Light Handlebar of LightSKIN has a built-in head light at the handle bar, it makes the design simple and can be used whenever it is necessary, and has a low concerns of theft & damage.

H_lightskin_07

How was built-in Light Handlebar Created?

H_lightskin_02Unique LED Hole shape in Can opener (Can tab) shape
In order to build the head light at the handle bar, more than 12㎜ hole shall be necessary, and if the hole of these sizes is carved into the handle bar, the strength or durability of handle bar can be deteriorated. To solve such problems, we have made unique LED Hole shape in Can opener (Can tab) shape. This hole prevents the stress applied surroundings of hole to be concentrated on a certain point, so that it eventually prevents the damages on handle bar upon the process of hole. With this technology, we could make 25.4㎜ handle bar in diameter with possible ISO-City to be passed up to 560㎜ and 31.8㎜ handle bar in diameter with possible ISO-Mountain to be passed up to 700㎜.

H_lightskin_03Special Tiny Light Module
We have newly developed a very tiny light module for being built-in at the handle bar. This does not only provide sufficient lights for night riders, but it has also shown a joyful & familiar design in combination of LEDs in small & large diameters.

18650_battery

18650 Lithium-Ion rechargeable Battery
General purpose 18650 Lithium-Ion Rechargeable Battery has been applied for easy battery exchange, and the battery can be separated and charged exclusively without taking a bicycle inside for charging.

Features of Lightskin Handlebar

LED : 1 High Brightness LED(200lumen)
Durability : About 6 hours (High Brightness with 2500mAh) / (Maximum) About 12 hours (Low brightness, Flickering with 2500mAh)
Batteries : 3.7volt 18650 Lithium-Ion rechargeable battery
Waterproof : Waterproof for everyday life
Operation : 3 modes (High, Low, Frickering)
Function : Battery low alarm, low voltage protection
Weight :
ㅡ LED module : Approximately 25 gram(without battery)
ㅡ Battery : Approximately 50~40 gram(18650 Lithium-Ion Rechargeable Battery)
ㅡ Handlebar : D25.4mm/W560mm : 220gram, D31.8/W660mm : 270gram

Diameter : D25.4mm, D31.8mm
Length :
ㅡ D25.4mm: 520mm, 560mm
ㅡ D31.8mm: 660mm, 680mm, 700mm
* All products's Design and specifications are subject to change without notice.

Manual of H-1 Built-in Light Handlebar

H1_manual222/>
