seatpost- SF

SFE – SC is a product of StVZO rear lighting modules and red COB lighting strips and complies with StVZO certification. The StVZO module at the top is a technology from the automobile industry and has a size of 17 mm width and a height of 5 mm. With a total COB length of 225mm, it is a complete product with perfect light performance and design elements.

Features

Diameter (see drawing)	27.2㎜ / 30.9㎜
Widths (see drawing)	D27.2mm(350mm) / D30.9mm(350, 400mm)
Color and surface finish	Matt Black
Seatpost Type	2 bolt clamp offset 9㎜ mechanical stopper 14㎜ from top
Material	Aluminum 6061 T6

Light unit

Light Module	high brightness StVZO rear light module
COB length	25㎜(Min, 1unit) to 225㎜(Max, 9units) SFE-C.4 100㎜ COB (4units) SFE-C.9 225㎜ COB (9units)
Power source	The on-board battery of the e-bike
Nominal voltage	DC 12V (6V-24V)
Power consumption	SFE-C.4 0.6W (100㎜ COB) SFE-C.9 1.4W (225㎜ COB)

ETC

Seatpost test standard	EN15194, EN17404, ISO-M
Compliant with standard or directive	CE, RoHS, StVZO §22a TA Nr.14b (Rear lights fot bicycles), IPX6
Package Contents	Rear light seatpost

Precautions

Operating Temperature

Min : -15° C Max : 45° C Optimum storage temperature : 20-25°C

Warranty

2 years from the date of purchase. In case of warranty, (replacement or repair), please contact the distributor through whom the product was purchased.

Waste Disposal

Old appliances and batteries must not be disposed of with normal household waste. According to EU Directive 2012/19/EU, the product must be disposed of properly at the end of its service life. Return the old device to a collection point for electronic waste or a recycling center

Shipping

Please be aware before order. The import tax will be charged to you separately. Taxes may vary depending on the country.

If you want to return or exchange, you will be charged a Fedex round-trip shipping fee. Prices are inclusive of basic international shipping.

Regions where additional shipping fee are generated will be charged at the payment window.

Returns and Exchanges

Returns : When returning the product, please contact the seller first to discuss the reason for return, delivery fee, shipping address, and etc. and then send the return product. Please send us unused products by prepaid, will refund you after confirming arrival. Exchanges : Please send us unused items by prepaid, and send $60~70 re-delivery courier fee depending on your location. After receipt the goods and courier fee, we will replace it with another product.
